ES30KWT-GT
Power Rating: 30 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | ES30KWT-GT |
|---|---|
| Warranty | 10 Years |
| Max. DC Input Power | 45kW |
| Max. DC Input Voltage | 1100Vdc |
| MPPT Voltage Range | 200–1000Vdc |
| Start Up Voltage | 200Vdc |
| Max. DC Input Current | 2×32Adc |
| Max. Short Circuit Input Current | 2×48Adc |
| No. of MPPT | 2 |
| Rated AC Grid Voltage | 3L+N+PE 220/380, 230/400V |
| Rated AC Grid Frequency | 50/60Hz |
| Rated AC Output Power | 30kW |
| No. of Phase | 3 |
| Max. Continuous Output Power | 33kW |
| Max. AC Output Current | 48A/Ph |
| Power Factor | 1 (-0.8 to +0.8) |
| Ingress Protection | IP65 |
| Interface | RS485 / RS232 / Wi-Fi / LAN |
| Dimension (L×W×H) | 450×485×210 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
78728 78728Enquiry Form
ES20KWT-GT
Power Rating: 20 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | ES20KWT-GT |
|---|---|
| Warranty | 10 Years |
| Max. DC Input Power | 30kW |
| Max. DC Input Voltage | 1100Vdc |
| MPPT Voltage Range | 150–1000Vdc |
| Start Up Voltage | 150Vdc |
| Max. DC Input Current | 2×32Adc |
| Max. Short Circuit Input Current | 2×48Adc |
| No. of MPPT | 2 |
| Rated AC Grid Voltage | 3L+N+PE 220/380, 230/400V |
| Rated AC Grid Frequency | 50/60Hz |
| Rated AC Output Power | 20kW |
| No. of Phase | 3 |
| Max. Continuous Output Power | 22kW |
| Max. AC Output Current | 32A/Ph |
| Power Factor | 1 (-0.8 to +0.8) |
| Ingress Protection | IP65 |
| Interface | RS485 / RS232 / Wi-Fi / LAN |
| Dimension (L×W×H) | 370×535×192 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
ES15KWT-GT
Power Rating: 15 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | ES15KWT-GT |
|---|---|
| Warranty | 10 Years |
| Max. DC Input Power (kW) | 22.5kW |
| Max. DC Input Voltage (V) | 1100V |
| Start-up DC Input Voltage (V) | 150V |
| MPPT Operating Range (V) | 150–1000V |
| Max. DC Input Current (A) | 20+32A |
| Max. Short Circuit Current (A) | 30+48A |
| No. of MPP Trackers | 2 |
| Rated Output Power (kW) | 15kW |
| Rated Output Power (VA) | 16.5kVA |
| Nominal Output Voltage / Range (V) | 3L+N+PE 220/380V, 230/400V |
| Rated Grid Frequency (Hz) | 50/60Hz |
| Operating Phase | Three Phase |
| Max. AC Output Current (A) | 27A/PH |
| Surge Protection | Integrated (Type II) |
| Ingress Protection | IP65 |
| Interface | RS485 / RS232 / WiFi / LAN |
| Dimension (L*W*H) | 370×535×192 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
ES10KWT-GT
Power Rating: 10 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | ES8KWT-GT |
|---|---|
| Warranty | 10 Years |
| Max. DC Input Power (kW) | 12kW |
| Max. DC Input Voltage (V) | 1100V |
| Start-up DC Input Voltage (V) | 150V |
| MPPT Operating Range (V) | 150–1000V |
| Max. DC Input Current (A) | 15+15A |
| Max. Short Circuit Current (A) | 25+25A |
| No. of MPP Trackers | 2 |
| Rated Output Power (kW) | 8kW |
| Rated Output Power (VA) | 8.8kVA |
| Nominal Output Voltage / Range (V) | 3L+N+PE 220/380V, 230/400V |
| Rated Grid Frequency (Hz) | 50/60Hz |
| Operating Phase | Three Phase |
| Max. AC Output Current (A) | 13.5A/PH |
| Surge Protection | Integrated (Type III) |
| Ingress Protection | IP65 |
| Interface | RS485 / WiFi / Wire Ethernet / GPRS (Optional) |
| Dimension (L*W*H) | 370×535×192 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
ES8KWT-GT
Power Rating: 8 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | ES8KWT-GT |
|---|---|
| Warranty | 10 Years |
| Max. DC Input Power (kW) | 12kW |
| Max. DC Input Voltage (V) | 1100V |
| Start-up DC Input Voltage (V) | 150V |
| MPPT Operating Range (V) | 150–1000V |
| Max. DC Input Current (A) | 15+15A |
| Max. Short Circuit Current (A) | 25+25A |
| No. of MPP Trackers | 2 |
| Rated Output Power (kW) | 8kW |
| Rated Output Power (VA) | 8.8kVA |
| Nominal Output Voltage / Range (V) | 3L+N+PE 220/380V, 230/400V |
| Rated Grid Frequency (Hz) | 50/60Hz |
| Operating Phase | Three Phase |
| Max. AC Output Current (A) | 13.5A/PH |
| Surge Protection | Integrated (Type III) |
| Ingress Protection | IP65 |
| Interface | RS485 / WiFi / Wire Ethernet / GPRS (Optional) |
| Dimension (L*W*H) | 370×535×192 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
EGT-10K-3P2M
Power Rating: 10 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | EGT-10K-3P2M |
|---|---|
| Max. DC Power (W) | 13000 |
| Max. DC Voltage (V) | 1100 |
| MPPT Voltage Range (V) | 120-1000 |
| MPPT Full Power Voltage Range (V) | 480-850 |
| Rated Input Voltage (V) | 600 |
| Start-up Voltage (V) | 140 |
| Max. Input Current (A) / MPPT | 20 |
| Max. Short Current (A) / MPPT | 30 |
| No. of MPPT | 2 |
| Max. AC Output Apparent Power (VA) | 11000 |
| Nominal AC Output Active Power (W) | 10000 |
| Max. Output Current (A) | 16 |
| Nominal Output Voltage (V) | 230 |
| Grid Voltage Range | 220Vac–380Vac |
| Nominal Output Frequency (Hz) | 50/60Hz |
| Grid Frequency Range | 45–55Hz / 55–65Hz |
| Grid Connection Form | 3L+N+PE |
| Protection Degree | IP65 |
| Communication Interface | RS482/RS232 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
EGT-8K-3P2M
Power Rating: 8 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | EGT-8K-3P2M |
|---|---|
| Max. DC Power (W) | 10400 |
| Max. DC Voltage (V) | 1100 |
| MPPT Voltage Range (V) | 120-1000 |
| MPPT Full Power Voltage Range (V) | 480-850 |
| Rated Input Voltage (V) | 600 |
| Start-up Voltage (V) | 140 |
| Max. Input Current (A) / MPPT | 20 |
| Max. Short Current (A) / MPPT | 30 |
| No. of MPPT | 2 |
| Max. AC Output Apparent Power (VA) | 8800 |
| Nominal AC Output Active Power (W) | 8000 |
| Max. Output Current (A) | 12.8 |
| Nominal Output Voltage (V) | 230 |
| Grid Voltage Range | 220Vac–380Vac |
| Nominal Output Frequency (Hz) | 50/60Hz |
| Grid Frequency Range | 45–55Hz / 55–65Hz |
| Grid Connection Form | 3L+N+PE |
| Protection Degree | IP65 |
| Communication Interface | RS482/RS232 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
EGT-5K-3P2M
Power Rating: 5 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | EGT-5K-3P2M |
|---|---|
| Max. DC Power (W) | 6500 |
| Max. DC Voltage (V) | 1100 |
| MPPT Voltage Range (V) | 120-1000 |
| MPPT Full Power Voltage Range (V) | 350-850 |
| Rated Input Voltage (V) | 600 |
| Start-up Voltage (V) | 140 |
| Max. Input Current (A) / MPPT | 20 |
| Max. Short Current (A) / MPPT | 30 |
| No. of MPPT | 2 |
| Max. AC Output Apparent Power (VA) | 5500 |
| Nominal AC Output Active Power (W) | 5000 |
| Max. Output Current (A) | 8 |
| Nominal Output Voltage (V) | 230 |
| Grid Voltage Range | 220Vac–380Vac |
| Nominal Output Frequency (Hz) | 50/60Hz |
| Grid Frequency Range | 45–55Hz / 55–65Hz |
| Grid Connection Form | 3L+N+PE |
| Protection Degree | IP65 |
| Communication Interface | RS482/RS232 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
EGT-6K-1PIM
Power Rating: 6 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | EGT-6K-1PIM |
|---|---|
| Max. DC Power (W) | 9000 |
| Max. DC Voltage (V) | 600 |
| MPPT Voltage Range (V) | 70–550 |
| MPPT Full Power Voltage Range (V) | 320–550 |
| Rated Input Voltage (V) | 360 |
| Start-up Voltage (V) | 70 |
| Max. Input Current (A) / MPPT | 20 |
| Max. Short Current (A) / MPPT | 30 |
| No. of MPPT | 1 |
| Max. AC Output Apparent Power (VA) | 6600 |
| Nominal AC Output Active Power (W) | 6000 |
| Max. Output Current (A) | 28.7 |
| Nominal Output Voltage (V) | 230 |
| Grid Voltage Range | 195.5Vac–253Vac |
| Nominal Output Frequency (Hz) | 50/60Hz |
| Grid Frequency Range | 45–55Hz / 55–65Hz |
| Grid Connection Form | L+N+P |
| Protection Degree | IP65 |
| Communication Interface | RS232 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
Enquiry Form
EGT-5K-1PIM
Power Rating: 5 KW
Warranty: 10 Years
Charger: MPPT
Consumer Benefits
Constant Power Supply
Use Of Renewable Resource
Power Monitoring
Power Maximization
Features
Max Efficiency98.5%
Low Startup Dc Voltage
Max DcOverloading 30%
Wide AcVoltage Range
Type-2 Spd EnabledAc and Dc Side
Eastman Solar App For Remote Monitoring 24*7
Built In ZeroExport Function
IP 65Enclosure
Technical Specification
| PARAMETER | EGT-5K-1PIM |
|---|---|
| Max. DC Power (W) | 7500 |
| Max. DC Voltage (V) | 600 |
| MPPT Voltage Range (V) | 70–550 |
| MPPT Full Power Voltage Range (V) | 270–550 |
| Rated Input Voltage (V) | 360 |
| Start-up Voltage (V) | 70 |
| Max. Input Current (A) / MPPT | 20 |
| Max. Short Current (A) / MPPT | 30 |
| No. of MPPT | 1 |
| Max. AC Output Apparent Power (VA) | 5500 |
| Nominal AC Output Active Power (W) | 5000 |
| Max. Output Current (A) | 24 |
| Nominal Output Voltage (V) | 230 |
| Grid Voltage Range | 195.5Vac–253Vac |
| Nominal Output Frequency (Hz) | 50/60Hz |
| Grid Frequency Range | 45–55Hz / 55–65Hz |
| Grid Connection Form | L+N+P |
| Protection Degree | IP65 |
| Communication Interface | RS232 |
Applications
Home
Office
Industrial Units
Hospitals
Schools
Petrol Pump
Blogs
Solar Inverters
Harnessing Solar Power - A Sustainable Energy Solution for Your Home
Solar power has changed the game in a society battling with the pressing need for sustainable energy options. Solar energy harnesses the sun's abundant energy.
Solar Inverters
What Is A Solar Power Conditioning Unit? How Does It Work?
A power conditioning unit is a device used to improve and maintain the quality of power delivered to any device or electrical load equipment.
Solar Inverters
All You Need to Know About Grid Tie Inverter
Grid Tie Inverter is the vital link between your solar panels and the electrical grid.Its primary role is to transform your solar panels' direct current (DC) into alternating current (AC), making i
FAQs
What is a Solar Inverter?
A solar inverter converts the DC electricity generated by your solar panels into AC electricity, making it usable for your home or business. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
How many solar panels should I connect with my solar inverter?
Connect enough solar panels to match the capacity of your inverter, ensuring optimal performance and efficient energy production for your needs. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How much electricity bill will I save when I use an Eastman solar inverter?
Using our Eastman solar inverter can save you up to 70% on your electricity bills by significantly reducing your reliance on grid electricity. Know your exact savings by using our Grid Tie Solar Calculator.
What does a solar inverter do?
A solar inverter converts DC electricity from your solar panels into AC electricity for your household appliances, enabling you to use solar power. We have a complete range of Solar Inverters for your every need. Our portfolio includes Off Grid Solar Inverters (PWM and MPPT based) and Grid Tie Solar Inverters with the best performance and reliability in the industry.
What are the types of solar inverters?
Our range of Solar Inverters include Off Grid Solar Inverters and Grid Tie Solar Inverters, each suited for different solar power system setups. Explore our complete range of Solar Inverters now!
How to choose a solar inverter?
Choose a solar inverter based on your energy needs, system size, and compatibility with your solar panels to ensure efficient energy conversion. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
How to calculate solar inverter size?
To calculate your solar inverter size, match it to the total wattage of your solar panels, ensuring the inverter capacity meets or exceeds this value. Use our Off Grid Solar Calculator or Grid Tie Solar Calculator for our recommendations as per your requirement.
What is PV in a solar inverter?
PV stands for photovoltaic, referring to the technology that converts sunlight into electricity through solar panels in your solar power system.
